Godox KNOWLED P1200R Hard RGBWW LED Panel

11.P1200RHARD

Product Features:

For Film, Broadcast & Video Production
Output: 136,000 Lux at 1m (5600K)
1800-10,000K CCT; RGB Colour Control
CRI 96 | TLCI 98
Onboard, DMX/RDM, CRMX & App Control
Fan Cooled
14 Effects, Green-Magenta Adjustments
0-100% Dimming with Four Curves
Includes Power Cable

Configuration Options:

$7,750.00
Stock Level:
In Stock
Check Location Availability
Make an Enquiry

Godox KNOWLED P1200R Hard RGBWW LED Panel

Add To Cart
$7,750.00

Description

As Godox pushes the range of its high-powered LED series, the KNOWLED P1200R Hard RGB LED Light Panel delivers strong output combined with powerful features and advanced control methods. Designed for those who operate in environments like large film and broadcast studios, the P1200R Hard's LED system produces a wash of extremely bright light with a suite of RGB settings. The panel offers a wide CCT range of 1800 to 10,000K, precise brightness adjustments, four dimming curves, a green-to-magenta shift, 14 lighting effects, and other convenient features. A variety of control methods allow you to adjust and control your light effortlessly and simplify your workflow. Measuring 83.39 x 60.6 x 16.99 cm (Fixture with Yoke) the P1200R Hard is significantly larger and brighter than the P600R Hard unit. The panel supports 100 to 240 VAC, which makes it reliable for use anywhere in the world.

Potent Output
The P1200R Hard's name reflects its characteristics by employing special lenses on the LEDs to focus and maximize the light output. This model draws 1200W and produces beams as intense as 136,000 lux at a distance of 1m (5600K).

Extended Control Methods
The P1200R Hard doesn't tie you down to a single control method, but it gives you the flexibility to adjust and manipulate the light onboard or remotely. The panel supports DMX 512/RDM control, and wireless LumenRadio/CRMX. Rounding out the versatility of the panel is the Godox Light app, with the option to control the light via Bluetooth from up to 30m away.

RGBW Features
For the whole RGBW color spectrum, 360 hues can have saturation adjusted to suit the atmosphere of any shoot. Toggle between the panel's RGBW, HSI, CCT, Gel, XY, and FX modes for a vast array of options to enhance the dynamism of your scenes.

Colour Accuracy
The panel also boasts superior colour accuracy, rating at 96 and 98 for both the CRI and TLCI standards, respectively. The P1200R Hard's red, green, blue, and white LEDs render colour fidelity at all times.

Four Dimming Curves
The light allows for dimming from 0 to 100% in 0.1% increments along four dimming curves: linear, S-curve, exponential, and logarithmic.

14 Lighting Effects
Achieve satisfying lighting simulations and establish practical effects on set by choosing from flash, lightning, cloudy, broken bulb, TV, candle, fire, fireworks, explosion, welding, police car, SOS, RGB cycle, and party presets.

Efficient Fan Cooling
Despite its power, the panel has an effective fan-cooled system that ensures rapid heat dissipation to maintain optimal working conditions and longevity of the device. You can even choose between silent, auto, medium-speed, and high-speed fan settings.

Widely Compatible
The P1200R Hard comes with no integrated diffusion, but it accepts an array of separately available modifiers that include a Godox space light softbox and a softbox with grid.


Godox P1200R Specs

Key Specs
Item Type
1x LED Light Panel
Included Storage Case
No
Photometrics
1800K:
7051 fc / 75,900 Lux at 3.3' / 1 m*
889 fc / 9570 Lux at 9.8' / 3 m
347 fc / 3740 Lux at 16.4' / 5 m
194 fc / 2090 Lux at 23' / 7 m
120 fc / 1300 Lux at 29.5' / 9 m
2800K:
11,519 fc / 124,000 Lux at 3.3' / 1 m*
1439 fc / 15,500 Lux at 9.8' / 3 m
565 fc / 6090 Lux at 16.4' / 5 m
318 fc / 3430 Lux at 23' / 7 m
201 fc / 2170 Lux at 29.5' / 9 m
3200K:
11,426 fc / 123,000 Lux at 3.3' / 1 m*
1430 fc / 15,400 Lux at 9.8' / 3 m
562 fc / 6050 Lux at 16.4' / 5 m
315 fc / 3400 Lux at 23' / 7 m
199 fc / 2150 Lux at 29.5' / 9 m
4300K:
11,891 fc / 128,000 Lux at 3.3' / 1 m*
1477 fc / 15,900 Lux at 9.8' / 3 m
579 fc / 6240 Lux at 16.4' / 5 m
326 fc / 3510 Lux at 23' / 7 m
206 fc / 2220 Lux at 29.5' / 9 m
5600K:
12,634 fc / 136,000 Lux at 3.3' / 1 m*
1588 fc / 17,100 Lux at 9.8' / 3 m
617 fc / 6650 Lux at 16.4' / 5 m
349 fc / 3760 Lux at 23' / 7 m
220 fc / 2370 Lux at 29.5' / 9 m
6500K:
13,656 fc / 147,000 Lux at 3.3' / 1 m*
1718 fc / 18,500 Lux at 9.8' / 3 m
665 fc / 7160 Lux at 16.4' / 5 m
376 fc / 4050 Lux at 23' / 7 m
236 fc / 2550 Lux at 29.5' / 9 m
8500K:
12,727 fc / 137,000 Lux at 3.3' / 1 m*
1570 fc / 16,900 Lux at 9.8' / 3 m
610 fc / 6570 Lux at 16.4' / 5 m
344 fc / 3710 Lux at 23' / 7 m
218 fc / 2350 Lux at 29.5' / 9 m
10000K:
11,612 fc / 125,000 Lux at 3.3' / 1 m*
1449 fc / 15,600 Lux at 9.8' / 3 m
561 fc / 6040 Lux at 16.4' / 5 m
317 fc / 3420 Lux at 23' / 7 m
200 fc / 2160 Lux at 29.5' / 9 m

*Standardized Measurement Supplied by the Manufacturer

Colour Temperature
1800 to 10,000K
Colour Modes
RGB, Daylight, Tungsten
Colour Accuracy Standard
CRI 96
TLCI 98
Dimming
Built-In Dimmer
 • 0 to 100%
Front Accessory Mount
Proprietary
Wireless Remote Control Type
Bluetooth
Wireless CRMX
Power Source
AC Power (Cable Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
1500 W (Maximum)
Fixture Mounting
Not Specified by Manufacturer
Light Fixture
Item Type
1x LED Light Panel
Included Storage Case
No
Photometrics
1800K:
7051 fc / 75,900 Lux at 3.3' / 1 m*
889 fc / 9570 Lux at 9.8' / 3 m
347 fc / 3740 Lux at 16.4' / 5 m
194 fc / 2090 Lux at 23' / 7 m
120 fc / 1300 Lux at 29.5' / 9 m
2800K:
11,519 fc / 124,000 Lux at 3.3' / 1 m*
1439 fc / 15,500 Lux at 9.8' / 3 m
565 fc / 6090 Lux at 16.4' / 5 m
318 fc / 3430 Lux at 23' / 7 m
201 fc / 2170 Lux at 29.5' / 9 m
3200K:
11,426 fc / 123,000 Lux at 3.3' / 1 m*
1430 fc / 15,400 Lux at 9.8' / 3 m
562 fc / 6050 Lux at 16.4' / 5 m
315 fc / 3400 Lux at 23' / 7 m
199 fc / 2150 Lux at 29.5' / 9 m
4300K:
11,891 fc / 128,000 Lux at 3.3' / 1 m*
1477 fc / 15,900 Lux at 9.8' / 3 m
579 fc / 6240 Lux at 16.4' / 5 m
326 fc / 3510 Lux at 23' / 7 m
206 fc / 2220 Lux at 29.5' / 9 m
5600K:
12,634 fc / 136,000 Lux at 3.3' / 1 m*
1588 fc / 17,100 Lux at 9.8' / 3 m
617 fc / 6650 Lux at 16.4' / 5 m
349 fc / 3760 Lux at 23' / 7 m
220 fc / 2370 Lux at 29.5' / 9 m
6500K:
13,656 fc / 147,000 Lux at 3.3' / 1 m*
1718 fc / 18,500 Lux at 9.8' / 3 m
665 fc / 7160 Lux at 16.4' / 5 m
376 fc / 4050 Lux at 23' / 7 m
236 fc / 2550 Lux at 29.5' / 9 m
8500K:
12,727 fc / 137,000 Lux at 3.3' / 1 m*
1570 fc / 16,900 Lux at 9.8' / 3 m
610 fc / 6570 Lux at 16.4' / 5 m
344 fc / 3710 Lux at 23' / 7 m
218 fc / 2350 Lux at 29.5' / 9 m
10000K:
11,612 fc / 125,000 Lux at 3.3' / 1 m*
1449 fc / 15,600 Lux at 9.8' / 3 m
561 fc / 6040 Lux at 16.4' / 5 m
317 fc / 3420 Lux at 23' / 7 m
200 fc / 2160 Lux at 29.5' / 9 m

*Standardized Measurement Supplied by the Manufacturer
Color Temperature
1800 to 10,000K
Color Modes
RGB, Daylight, Tungsten
Color Accuracy Standard
CRI 96
TLCI 98
Dimming
Built-In Dimmer
 • 0 to 100%
Cooling System
Fan
Built-In Flash
No
Umbrella Mount
No
Front Accessory Mount
Proprietary
Connectivity
Wireless Remote Control Type
Bluetooth
Wireless CRMX
Mobile App Compatible
Yes: Android & iOS
App Name: Godox Light
Wireless Range
30 m (Bluetooth)
Power & I/O
Power Source
AC Power (Cable Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Included Adapter / Cable
1x Unspecified to Unspecified Cable
Power Consumption
1500 W (Maximum)
Mounting
Yoke Type
Manually-Operated Yoke
Fixture Mounting
Not Specified by Manufacturer
Environmental
Environmental Protection
No
General
Display
Yes
Dimensions
83.39 x 60.6 x 16.99 cm (Fixture with Yoke)
Weight
18.5 kg (Fixture with Yoke)
